Fire cable JEH(St)H 2x2x1.5mm ORANGE

Description

Fire cable JEH(St)H…Bd FE180 PH120 2x2x1.5 mm²+0.8, fire resistance 120 minutes, compatibility E30/E90; manufacturer 2M Kablo, 3T00000113-5-500; Wire diameter: 1.5 mm; Conductor: twisted pairs with fiberglass protection, 100% copper; Wire colors: according to -VDE0815; Sheath: Halogen free, and flame resistant, orange color (RAL2004Orange), Wire ResistantSilicon Rubber (EN 50363-1, BS7655EI2); Packaging: drum 500 meters; OperatingVoltage 300V; Flame Retardancy IEC/EN 60332-1, IEC/EN 60332-3-24; Fire Resistance IEC60331-21,EN 50200 (PH120); Smoke Density IEC/EN 61034-1/2; CorrosiveGases Measurement IEC /EN 60754-1/2; Min. Bending Radius: 10x cable diameter; Conductor Resistance 0.80mm – ≤36.6 Ω/km; 1.00 mm – ≤22.2 Ω/km; 1.50 mm² – ≤12.1 Ω/km
